If you have any requestment for shipping , Pls connect with us .Thank you ;
Function:
* Battery 1 pcs ,USB Data Cable 1 pcs ,Adapter 1 pcs , Screen Protector 1 pcs
| Structural Parameter |
|
| Dimensions |
172mm(L) X 80mm(W) X 27mm(D) |
| Weight |
<500g |
| Display Screen |
5.0 inch IPS 720 * 1280 px with Multi-point touch capactive screen |
| Expand Port |
SIM card, micro SD (TF) Card |
| Communication Interface |
USB2.0 Device |
| Input Mode |
Standard Stylus, touching input or keyboard input |
| Battery Capacity |
Rechargeable Li-polymer Battery 3.7V 4800mAh |
| Frequency |
8ohm 1W speaker |
| Key |
13pcs soft silicon key |
| Performance Parameter |
|
| OS |
Android 7.0 |
| CPU |
ARM CORTEX-A53 64bit Quad-Core 1.5G |
| RAM |
2G RAM |
| Flash ROM |
Standard 16G NAND Flash Storage |
| micro SD/TF port (Max up to 32G) |
|
| Data Communication |
|
| WI-FI |
Support IEEE802.11 a/b/G/n protocol, it need effective wireless LAN signal cover |
| FDD/TDD-LTE 4G |
TDD-LTE (B38,B39,B40,B41),FDD-LTE (B1,B3) |
| WCDMA 3G |
B1,B2,B5,B8 |
| GSM 2G |
GSM/edge/GPRS (850,900,1800,1900MHz) |
| bt |
Support bt 2.0+EDR/3.0+HS/4.1+HS, transmission distance is 5-10m |
| Standard Modules |
|
| Camera |
8MP autofocus camera with flash |
| GPS |
Support A-GPS |
| Operating Environment |
|
| Operating |
-20°C to 50°C |
| Storage Temperature |
-25°C to 70°C |
| Environment Humidity |
5%RH-95%RH(no condensation) |
| Drop Specifications |
6 sides can bear impact from 1.5m drop to cement floor in the range of operating temperature |
| Roll Specifications |
1000 times/0.5m, roll on 6 sides contact area |
| Sealed Environment |
IP66 |
| 1D Laser Scanner (OPTIONAL) |
|
| 1D Laser Scanner |
Mingde966, HoneywellN4313, |
| Resolution |
4Mil minimum width |
| Ambient Light |
10000ft.candles(107640 lux) |
| Scanning Speed |
104(±)12/sec (bothway) |
| Scanning Angle |
47o±35o(Standard) / 35o±3o(narrow angle) |
| Support Bar Code Type |
UPC/EAN, Code128, Code39, Code93,Code11, Interleaved 2 of 5, Discrete 2 of 5,Chinese 2 of 5, Codabar, MSI, RSS |
| 2D CMOS (OPTIONAL) |
|
| CMOS Scanner |
Honeywell N6603 |
| The Sensor Resolution |
752(level)×480(vertical)pels(gray level) |
| Ambient Light |
All dark 9000ft.candles/96900 lux |
| focus element (VLD) |
655nm ± 10nm |
| Support bar code type |
PDF417,MicroPDF417,Composite, RSS,TLC-39, Datamatrix, QR code, micro QR code,Aztec, MaxiCode; Postal Codes: US PostNet,US Planet, UK Postal, Australian Postal, JapanPostal Dutch Postal (KIX)3 |
| LF RFID Reader (Optional) |
|
| Frequency |
125kHz, |
| Protocol |
ISO11784/5, ISO18000-2 |
| Range |
3-5cm |
| NFC Reader (Optional) |
|
| Frequency |
13.56MHz |
| Protocol |
ISO/IEC 18092 (ECMA 340) |
| Range |
3-5cm |
| UHF RFID Reader (Optional) |
|
| Frequency (China) |
920 - 925MHz |
| Frequency (America) |
902 - 928MHz |
| Protocol |
EPC C1 GEN2 / ISO18000-6C |
| Antenna |
Linear polarisation (1.8dBi) / Circular polarisation (2.5dBi) |
| Power |
1W (typical 24dBm, +10dBm to +30dBm) |
| Range |
1-2m |
| Biometric Fingerprint (Optional) |
|
| Sensor |
TCS2SS |
| Sensor type |
Capacitive Sensor |
| Function |
Enrollment, compare, deletion etc. |
| Resolution |
508DPI |
| Memory |
1,000 PCS fingerprints |
| 58mm thermal printer(Optional) |
|
| Printer |
Integrete 2inch Direct thermal line printing |
| Printing paper width |
58mm |
| Printing speed |
50mm/s |
| Printer service life |
50km |
| Roll Diameter |
φ≤25mm |
